7408 Quad 2 Input AND Gate Logic IC

The 7408 Quad 2-Input AND Gate Logic IC is a fundamental digital logic device that contains four independent AND gates in a single 14-pin Dual In-line Package (DIP). Each gate performs the logical AND operation, making this IC essential for control logic, combinational circuit designs, and digital system implementations. The IC is widely used in both educational and industrial applications.

The 7408 series includes several popular logic family variants, such as SN74LS08, SN74LS08N (Low Power Schottky TTL), and SN74HC08, 74HC08 (High-Speed CMOS). The LS series is designed for reliable operation in standard TTL logic systems, while the HC series provides lower power consumption and wider operating voltage, ideal for interfacing with CMOS-based microcontrollers and circuits.

Whether you’re building timing circuits, control systems, or logic-based applications, the 7408 IC family provides fast switching performance, stable operation, and easy integration thanks to its standard DIP-14 form factor. Buy high-quality 7408 AND gate ICs and all major variants from eleberric.com, your trusted electronics source in Sri Lanka.

Specification

• IC Type: Quad 2-Input AND Gate

• Number of Gates: 4

• Inputs per Gate: 2

• Logic Families: TTL (SN74LS08, SN74LS08N), CMOS (SN74HC08, 74HC08)

• Voltage Range:

  • LS Series: 4.75V – 5.25V

  • HC Series: 2V – 6V

• Logic Compatibility: TTL or CMOS depending on variant

• Propagation Delay:

  • LS series: ~10 ns

  • HC series: ~8 ns

• Power Consumption:

  • LS series: Low

  • HC series: Ultra low

• Package Type: DIP-14

• Operating Temperature: 0°C to +70°C

• Dimensions: Approx. 19.3mm × 6.3mm × 3.3mm

• Weight: ~1.2g

Key Features

• Four independent 2-input AND gates

• Available in TTL (SN74LS08/N) and CMOS (SN74HC08, 74HC08) families

• Compatible with 5V logic systems

• DIP-14 package for easy prototyping

• Fast switching response and low power usage

• Ideal for use in control logic and digital processing

• Suitable for breadboards, PCBs, and embedded systems

Applications

• Digital logic circuit design

• Signal validation and control

• Industrial automation and logic controllers

• Educational logic gate training kits

• Microcontroller-based input/output logic

• Robotics and embedded electronics systems
