380 DC Motor 6V – 12V DC 38000 RPM

The 380 DC Motor is a versatile, high-speed brushed DC motor suitable for a wide range of electronics, robotics, and mechanical projects. Operating efficiently between 5V to 12V, this motor delivers up to 38,000 RPM, making it an ideal choice for applications that require speed, precision, and compact design.

It is widely used in remote-controlled vehicles, mini tools, robotics, and DIY fan or cooling systems. With a sturdy metal casing, it offers excellent durability while keeping the weight low. Whether you’re building an Arduino-based robot or upgrading your RC project, this motor delivers reliable and consistent performance.

Available now at eleberric.com, your one-stop shop for quality electronics components in Sri Lanka.

Specifications

• Model: RS-380

• Motor Type: Brushed DC Motor

• Operating Voltage Range: 5V – 12V DC

• Speed & Current Ratings:

  • 5.0V: 16,500 RPM @ 0.80A

  • 6.0V: 20,000 RPM @ 0.90A

  • 9.0V: 30,000 RPM @ 0.92A

  • 11.1V: 36,000 RPM @ 1.20A

• Max Speed (No Load): Up to 38,000 RPM

• Shaft Diameter: 2mm

• Shaft Length: Approx. 10mm

• Motor Body Diameter: Approx. 24mm

• Motor Length: Approx. 30mm

• Weight: Approx. 50g

• Bearings: Sleeve-type

• Mounting Holes: Standard for model integration

Key Features

• High-speed motor for fast applications

• Operates over a wide voltage range (5V–12V)

• Compact, lightweight, and easy to mount

• Strong and durable metal housing

• Reliable performance in high-RPM conditions

• Compatible with Arduino and other controllers

• Ideal for RC vehicles, fans, and small power tools

Applications

• RC cars, boats, and aircrafts

• DIY cooling fans and air movers

• Mini drills and electric screwdrivers

• Robotics motion control

• Educational STEM and Arduino projects

• Electronic hobby kits and tool systems

Order your 380 DC Motor today from eleberric.com and supercharge your next DIY or robotics build with high-speed performance and dependable quality!
